FAT Drift Rear Kit for BMW 1-Series E8X

FAT Rear Kit for BMW E8X Specifications

Manufactured by FAT, a drift specialist company based in Poland, this kit for BMW E8X allows to noticeably increase your vehicule's traction and handling via many adjustment possibilities. The alignment is optimized, the roll is minimized and the squat phenomenon that occurs during strong accelerations is reduced.

With this kit, the rear of your car is considerably stiffened and is a perfect complement to the manufacturer's steering lock kit. The knuckles have been designed to allow for a dual caliper per wheel set-up that is very popular in drifting.

Kit contents :

• 10 arms, including 6 adjustable
• 2 knuckles
• 4 bushings which has to be press and weld into stock subframe

Please note : This kit only fits 336x22 mm BMW E9x 330D or M3 brake discs. Wheel bearings are suitable for M3 E92 and 335i versions (outer diameter 85 mm, inner diameter 45 mm, height 41 mm). Wheel hubs must also come from an M3 E92. 18-inch wheels required.

This kit is 89 mm wider per side compared to stock. It is necessary to fit custom made axles or axles from other compatible models. The total width of this kit without spacers is 200 cm with 18x10.5J ET10 wheels. The total width of the front FAT kit is 200 cm with 8.5J ET30 wheels.
