Mishimoto Kit de tubería de refrigeración interna ford fiesta st, 2014+

Mishimoto Kit de tubería de refrigeración interna ford fiesta st, 2014+

Cooler Overall Size
44" x 9.00" x 5.5"

Cooler Core Size
28" x 8.25" x 3.5"

Crash Bar Specs
– Steel construction with black powdercoat
– Application-specific mounting holes
– 6.5 lbs

Hot-Side Intercooler Pipe Specs
– Made from polished mandrel-bent aluminium
– 2.25" I.D.
– Includes upper and lower intercooler pipes

Cold-Side Intercooler Pipe Specs
– Made from polished mandrel-bent aluminium
– 2.75" I.D.
– Includes upper and lower intercooler pipes

Purchase Includes
(1) Bar-and-Plate Intercooler
(1) Steel Crash Bar w/ Mounting Hardware
(2) Hot-Side Intercooler Pipes
(2) Cold-Side Intercooler Pipes
(1) BPV Flange Adapter
(1) Resistor Block Relocation Bracket w/ Mounting Hardware
(2) Lower Intercooler Brackets w/ Mounting Hardware
(1) Aluminium Overflow Can w/ Mounting Hardware
(1) Turbo to Hot Pipe Coupler (for stock turbo)
(1) Turbo to Hot Pipe Coupler (for aftermarket turbo)
(1) 2.25" Straight Coupler
(2) 2.75" Straight Couplers
(1) 2.75" x 3.25" Long Straight Coupler
(1) 2.00"-2.75" Transition Coupler
(1) BPV Recirculation Hose
(1) PCV hose
(1) 2.00" T-bolt Clamp
(4) 2.5" T-bolt Clamps
(7) 3" T-bolt Clamps
(1) 1.5" Worm-Gear Clamp
(1) Bypass Valve Gasket
(1) Black Nylon Hose Fitting, 3/4" I.D.
(1) Black Nylon Tee Hose Fitting, 3/4" I.D.
(1) 12" of Thermal Wrap

Note
Mishimoto recommends that this intercooler kit, with or without the optional air intake, is not used with the stock ECU programming. It is highly recommended that the customer is able to retune the vehicleÍs ECU after installing the intercooler kit. Power gains will vary depending on the size of the turbo, exhaust system, fuel system, and type of ECU tune that is applied to the vehicle.

This kit is rated for approximately 700 whp, or 30 psi of turbo boost. Exceeding these horsepower or pressure limits may require a custom-sized front-mount intercooler.

This FMIC kit is not compatible with OEM fog lights.Cooler Inlet / Outlet
2.75" I.D. / 3.00" O.D.

Cooler Weight
25.5 lbs

Cooler Tank Wall Thickness
3.5mm

Cooler Construction
Bar-and-plate with cast end tanks

Also Fits
02–07 Subaru WRX
04–07 Subaru STI
05–06 Saab 9-2x Aero

Engine Codes
EJ205
EJ255
EJ257

Chassis Codes
GD
GG

Turbo to Hot-Side Hose Specs (for Stock Turbo)
– 1.875" I.D. / 2.20" O.D. – On turbo outlet
– 5mm hose thickness
– Withstands up to 400°F (204°C) temps
– Fits on turbos with 1.97" (50mm) maximum compressor outlet size

Turbo to Hot-Side Hose Specs (for Aftermarket Turbo)
–2.00" I.D. / 2.40" O.D.–On turbo outlet
– 5mm hose thickness
– Withstands up to 400°F (204°C) temps
– Fits on turbos with 2.25" (57mm) maximum compressor outlet size

Intercooler pipe to throttle-body coupler specs
– 3.25" Length
– 2.75" I.D.
– 3.00" O.D.
– 4mm thick

BPV Hose Specs
– Application-specific bend for this kit
– 1.25" I.D.
– 1.50" O.D.
– 4mm thick

PCV Hose specs
– 17.5" length
– 0.45" I.D.
– 0.75" O.D.
– 4mm thick
